Features:
• Powerful 3,300 W heavy-duty motor with high power reserves and a long lifetime
• Full aluminium housing – durable and resistant
• Electronic – soft start, temperature control and over load protection cut-off, optical overload indication
• 3 speed oil bath gearbox – for optimal lubrication in all working positions, due to the developed oil pump
• Mechanical safety clutch
• Heavy duty PUR- Power cord
• Universal connection – fasten the motor to the drilling rig without any tools
• Integrated spirit level on the carriage and scale on the drilling rig – exact drilling
• Column swivel in three levels (75°/60°/45°)
• Steel column – robust, stable, buckling resistant
• Tooth rail separately exchangeable – easy to maintain
• Compact base with cut-out for quick action bracing unit
• Feed lever change without any tools – easy change at the work site
• Removeable wheel axle – easy transport
Uses:
• Wet drilling in reinforced concrete, natural stone and asphalt
• Civil engineering
Technical Data:
• Power input: 3.300 W
• Rated voltage: 230 V ~
• Rated speed: 180/400/780 rpm
• Drilling diameter: 71-450 mm
• Spindle connection: 1¼” UNC male
• Column length: 1,000 mm
• Hub: 620 mm
• Weight drilling unit: 35.8 kg
Supplied With:
• PLD 450 B + PLB 450 , drill bit not included
